G / NPT Thread Pneumatic Solenoid Valve , Internal Pilot Solenoid Valve 4N300 3NV300 Series
4N310 - 08 , 4N320 - 08 , 4N330C - 08 , 4N330E - 08 , 4N330P - 08 , 4N310 - 10 , 4N320 - 10 ,
4N330C - 10 , 4M330E - 10 , 4N330P - 10 , 3NV310 - 08 , 3NV320 - 08 , 3NV310 - 10 , 3NV320 - 10 .
Specification
Model : 4N310 - 08 , 4N330C - 08 , 4N330E - 08 , 4N310 - 10 , 4N330C - 10 , 4N330E - 10
4N320 - 08 , 4N330P - 08 , 4N320 - 10 , 4N330P - 10
Position and Way No. : Two - Position Five - Way , Three - Position Five - Way
Effective section area : 25mm ² ( CV = 1 . 40 ) , 18mm ² ( CV = 1 . 00 ) , 30mm ² ( CV = 1 . 68 )
Model : 3NV310 - 08 , 3NV320 - 08 , 3NV310 - 10 , 3NV320 - 10
Position and Way No. : Two – position Three - way
Effective Section Area : 25mm ² ( CV = 1 . 40 ) , 30mm ² ( CV = 1 . 68 )
Port Size : Air Inlet = Air Outlet = Exhaust = G1/ 4” , Air Inlet = Air Outlet =G3/ 8” Exhaust = G1/ 4 "
Working Medium : 40 Micron Filtered Air
Motion Pattern : Inner Guide Type
Working Pressure : 0 . 15 ~ 0 . 8MPa
Max . pressure Resistance : 1 . 2MPa
Temperature : -5 ~ 60 ℃
Power Consumption : - 15 % ~ + 10 %
Power Consumption : AC : 3. 5VA , DC : 3W
Insulation & Protection Class : F Class . IP65
Wiring Form : Lead Wire Or Connector Type
Highest Action Frequency : 5 Cycle / Sec
Shortest Excitation Time : 0. 05 Second
Life : 20 Million
Why choose us
1: Large stock for fast shipping .
2: High quality with competitive price .
3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .
5: Reliable quality assured and active after-sell service
FAQ
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples for the massive products .
Q: What ' s your business scope ?
A: Our business scope is air cylinder , air source treatment , air solenoid valve , motorize valve , pneumatic valve , quick fitting , etc .
Q: what types of products you can make ?
A: We can make many kinds of stainless steel materials processing . Valve / solenoid valve / electric valve / pneumatic valve and air cylinder products and so on .
Q: Do you company have specialized technical personnel ?
A: Do you company have specialized technical personnel , they can design the product which the most meet your requirements .
Our products are high quality with 12 month guarantee ,and support paypal payment.
